Toja Grid Adjustable upto 12x24 ft. Double Pergola Kit for 6x6 Wood Posts with KNECT 2x6 Top Rafter Brackets
Product Details
NOTICE: Please check with your municipality for permit requirements on this item before purchasing. Municipalities differ in permit requirements and may not accept such structures in your area.
Product details have been supplied by the manufacturer, and are hosted by a third party
LUMBER NOT INCLUDED
Double Pergola Kit for 6x6 Wood Posts with KNECT 2x6 Top Rafter Brackets
This Toja Grid Pergola Kit Includes
6 SOLO Brackets
4 TRIO Brackets
2 QUAD Brackets
32 KNECT 2x6 TOP RAFTER BRACKETS (common spacing is 8/10' section)
All hardware to attach to your lumber
- TRIO
- QUAD
- SOLO
- KINECT
- LUMBER NOT INCLUDED
Strong and Durable
Toja Grid brackets use high-quality steel covered in
weather-resistant coatings. We use the best materials
and manufacturing practices to ensure our products last.
Modular
Toja Grid is a modular pergola system that can connect in many ways to accommodate your needs and space with endless possibilities.
Quick Installation
Fast and easy assembly with no special tools required.
Canadian made Brackets
Toja Grid brackets are designed and made in Canada using Canadian Steel.
Non-Toxic
The paint and parts used in our brackets are non-toxic.
Recyclable
Toja Grid Brackets are recyclable.
Not included
Wood
Just add lumber. This allows you the freedom to select the type of wood to suit the style and budget for your build. Please take a bracket with you to ensure a proper fit.
Surface Hardware
Due to different building materials and requirements based on location, we advise on checking building codes and talking to your local hardware store for the best securing hardware for your specific surface.
FEATURES
Brackets
- Canadian made brackets using 12 gauge
- Canadian Steel Laser-cut, bent, and welded
- Weather-Ready: Coated in weather-resistant materials (E-Coat and Powder Coating)
- Welds on the inside for a clean quality look
- 5 year limited warranty
- Recyclable
- All hardware to attach lumber is included (Packaged with #12x1-1/2” Pan Rob/Phil combo drive 304 S.S Wood screws with black plastic head caps
DIMENSIONS LxWxH
- TRIO Box (1 box | 2 pieces) 39 cm x 40 cm x 40 cm (15.2 in. x 15.6 in. x 15.8 in.) (20.5 kg / 45 lbs)
- TRIO Box (1 box | 2 pieces) 39 cm x 40 cm x 40 cm (15.2 in. x 15.6 in. x 15.8 in.) (20.5 kg / 45 lbs)
- SOLO Box (1 box | 4 pieces) 69 cm x 22 cm x 25 cm (27.1 in. x 8.8 in. x 10.5 in.) (13.5 kg / 30 lbs)
- QUAD with SOLO Box (1 box | 2 pieces) 43 cm x 41 cm x 62 cm (17 in. x 16 in. x 24.5 in.) (17 kg / 38 lbs)
- QUAD with SOLO Box (1 box | 2 pieces) 43 cm x 41 cm x 62 cm (17 in. x 16 in. x 24.5 in.) (17 kg / 38 lbs)
- KNECTS Box (1 box | 16 pieces) 30 cm x 48 cm x 20 cm (12 in. x 19 in. x 8 in.) (18 kg / 40 lbs)
- KNECTS Box (1 box | 16 pieces) 30 cm x 48 cm x 20 cm (12 in. x 19 in. x 8 in.) (18 kg / 40 lbs)
DETAILS/ MATERIALS
Brackets
- 12 gauge Canadian Steel
- Exterior Bracket Arm Measurement: 14.80 cm x 14.80 cm (5.828 in. x 5.828 in.)
- Interior Bracket Arm Measurement: 14.27 cm x 14.27 cm (5.62 in. x 5.62 in.)
- Fastening Holes 0.635 cm (0.25 in.)
- Flange: 1.54 cm (1 in.)
- Securing Holes: 1.27 cm (0.5 in.)
